ACK700 Aluminium Upcut Mitre Saw

Large Capacity, Accurate & Safe Aluminium Cutting

Introducing the ACK700S Large Capacity Aluminium Mitre Saw! The New ACK700S has one of the largest cutting capacities in its class. Its 700mm Aluminium blade and powerful 3KW (4HP) motor can accurately perform straight cuts, 45º mitres and more extreme angles of up to 75º in either direction (Left & Right). The 700mm blade stroke is controlled by a sturdy Hydro-Pneumatic (air over oil) feed cylinder mounted on two linear rods; the feed rate of the blade can be adjusted via a turn knob on the front of the machine. To start the cutting action the operator presses two separate buttons on the front control panel, this means that both hands have to be used which increases safety for the operator.

Learn More →

Key Features:

  • 700mm Saw Blade
  • Large Cutting Capacity
  • Safe for operators
  • Fast Cutting action
  • Mitre to 75º Left & Right
  • 4 x Pneumatic Clamps
Enquire Now

Enquire

Description

The ACK700 incorporates a fully enclosed safety hood which is controlled via a pneumatic cylinder to open and close and an LED light system is used inside the hood to improve visibility when cutting. Profiles are held in place when cutting by 4 pneumatic clamp cylinders and a spray-mist lubrication system is used to help cut quality and blade life.

Features:

  • 700mm Aluminium TCT Saw Blade
  • 4KW (7HP) Sealed induction Motor
  • Hydro-Pneumatic adjustable blade feed
  • Mitre range of 0º – 75º Left and Right
  • Movable Back-Fence for increased cutting capacity
  • 2 x Horizontal Pneumatic Clamp
  • 2 x Vertical Pneumatic Clamps
  • Automatic safety hood
  • LED lighting for safety hood
  • Spray-Mist lade lubrication
  • Two hand safety operation

Technical

ACK700
Motor KW4 KW
Volt/Freq/Amp415v (3A+E) /50/15
Blade Diameter / Bore700mm / 38mm
Spindle RPM3000 RPM
Air Consumption60 Lt/minute
Air Pressure6 Bar
Air ConnectorNitto Male
Table Height (mm)1000mm
Machine Dimensions (mm)
(Width x Depth x Height)
1100 x 1380 x 1600mm
Packing Dimensions (cm)
(Length x Width x Height)
130 x 110 x 166cm
Net Weight (KG)500kg
Gross Weight (KG)550kg

Cutting Chart
