YILMAZ FR221 Template Router

FR221 Aluminium Template Router

How Can a Copy Router Help My Production?

Copy Routing is the quickest and most effective method for making cut-outs of any shape in Hollow sections and extrusions.
Copy Routers are primarily designed to work from an inter-changable, pre-designed metal template which is mounted at the back of the machine. The shape is transferred to the work piece by using one of the two copy pins to trace the template, then a specially designed self Drilling Router Cutter produces the desired cut-out onto the extrusion.
Copy Routers can also produce rectangular, square shapes or slots without a template by setting the four head guides to the desired position.
The Routing method is fast, accurate and can be utilized with unskilled labor. The reliability and versatility has been proven under years of continuous production conditions.

Learn More →

Key Features:

  • Make Lock Cut-outs quick & easy
  • Traces from Metal Template
  • Pneumatic Clamps
  • Twin Copy Pins
  • Spray Mist Lubricator
  • Includes Stand
Enquire Now

Enquire

  • This field is for validation purposes and should be left unchanged.
SKU: FR221TemplateRouter240v Categories: , Tags: ,

Description

The Luna FR221 Template Router is the work horse of the Luna Router range.  The features and quality the FR221 offers have never been available in an entry level router before.  With a sealed induction motor quality Festo and Telemecanique electrical components the FR221 is designed to give a long, trouble free life.

Twin Tracer Pins are standard along with Pneumatic Clamps, Pneumatic Spray Mist system, Length Stops (left and right), air gun and superb quality construction.

  • Produce lock cut-outs quick & easily
  • 1.6HP 240v 12’000rpm motor
  • Traces from Metal template
  • Maximum slot 260mm x 110mm
  • Template size 490mm x 120mm
  • Twin copy pins
  • Pneumatic clamps
  • Spray mist lubricator
  • Enclosed cabinet
  • Air duster gun
  • European made
  • Includes 2 end stops
  • Includes 5mm HSS cutter
  • Includes Lockwood template for 591F, 590F, 591F Sliding Door Striker, 3582 Striker & 590F Bolt Hole.

Additional information

Weight 95.0000 kg
Dimensions 76.0000 × 59.0000 × 151.0000 cm

Technical

FR221
Motor KW800W
Volt/Freq/Amp240v AC /50/13
Tool Holder Diameter8mm
Spindle RPM14,000 RPM
Air Consumption24 Lt/minute
Air Pressure6 Bar
Air ConnectorNitto Male
Table Height (mm)900mm
Machine Dimensions (mm)
(Width x Depth x Height)		560 x 500 x 1520mm
Packing Dimensions (cm)
(Length x Width x Height)		76 x 59 x 151cm
Net Weight (KG)75kg
Gross Weight (KG)95kg
