KD402 Aluminium Double Mitre Saw

Ideal for fabricators wanting to get the competitive edge

Ideal for the budget concerned. This machine features a fully welded sheet metal base (a feature not found on expensive German machines)that two 50mm ground steel rails sit on. This offers superior rigidity . The KD402 uses two 400mm blades and features a Elgo Digital display for the cut length. Two hand safety is provided to the operator as well as full guarding around the blades. A two stage rapid feed option is available for cutting small profiles.

Learn More →

Key Features:

  • Twin 400mm Blades
  • 2 x 3.0HP Motors
  • DIgital Measuring
  • Cuts 90º - 45º
  • Two Hand Safety Controls
  • Pneumatic Clamps
Enquire Now


  • This field is for validation purposes and should be left unchanged.
SKU: KD402AluminiumDouble Categories: , , Tags: , ,



Ideal for fabricators wanting to get the competitive edge.

  • Twin 400mm blade heads
  • 2 x 3.0HP Hi Torque (Green Power 80%  efficient)
  • 6.0HP total cutting power
  • Two hand safety operation
  • Manual mobile head (motorized optional)
  • Pneumatic clamping
  • Pneumatic head lock
  • Digital measuring +/- 0.1mm
  • Cut length 530mm – 3455mm
  • Spray-mist blade lubricator
  •  Centre profile support
  • Double your cutting efficiency


KD402 Cutting Capcity


Motor KW2.2 KW x 2
Volt/Freq/Amp415v (3A+E) /50/15
Blade Diameter / Bore400mm x 2 / 30mm
Spindle RPM3000 RPM
Air Consumption46 Lt/minute
Air Pressure6 Bar
Air ConnectorNitto Male
Table Height (mm)900mm
Machine Dimensions (mm)
(Width x Depth x Height)
4100 x 1100 x 1460mm
Packing Dimensions (cm)
(Length x Width x Height)
430 x 75 x 170cm
Net Weight (KG)487kg
Gross Weight (KG)622kg

Cutting Chart
